Audi S4 B8 (2008-2011) comfort system central control wiring diagram
This page shows the only wiring diagram for the component.comfort system central control, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
comfort system central control wiring diagram (1 of 1)
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL (BEHIND LEFT END OF DASH)
FUSE 9
FUSE CARRIER 3
GRY/BLU WIRE
HOT AT ALL TIMES
MODULE (RIGHT SIDE OF TRUNK)
POWER SUNROOF CONTROL MODULE (CENTER FRONT OF ROOF)
RED/BLU WIRE
SUNROOF REGULATOR
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
Go to component -> Power top/sunroof circuit, without roof blind -> COMFORT SYSTEM CENTRAL CONTROL
