Radio/navigation circuit, with rns-e with bose for Audi S4 B7 (2004-2008)

2 1 +2 -1 BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CD CHANGER UNIT COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM CONTROL MODULE FOR NAVIGATION W/ CD- MECHANISM FUSE 39 FUSE HOLDER GRN WIRE GRN/BLU WIRE GRY WIRE HOT AT ALL TIMES INSIDE LOUDSPEAKER LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR MIDRANGE SPEAKER NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER ROOF ANTENNA SATELLITE RADIO TELEPHONE MICROPHONE TELEPHONE PREPARATION WIRING VIO WIRE VIO/GRY WIRE VIO/RED WIRE W/ SATELLITE RADIO W/O SATELLITE RADIO WHT WIRE WHT/YEL WIRE YEL WIRE

AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING) AMPLIFIER ANTENNA AVANT BASS LOUDSPEAKER BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM GPS ANTENNA SPLITTER GRN WIRE GRN/BLU WIRE GRY WIRE INSIDE LOUDSPEAKER INSIDE MICROPHONE 1 2 INSTRUMENT CLUSTER LEFT ANTENNA MODULE (AVANT) LEFT FRONT BASS SPEAKER 2 1 -1 +2 LEFT FRONT MIDRANGE SPEAKER LEFT REAR SIDE WINDOW ANTENNA COMFORT SYSTEM NAVIGATION SYSTEM ANTENNA NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE RADIO CONTROLS REAR WINDOW DEFOGGER W/ WINDOW RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RIGHT ANTENNA MODULE (AVANT) RIGHT FRONT BASS SPEAKER 2 1 +2 -1 RIGHT FRONT MIDRANGE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR MIDRANGE SPEAKER RIGHT REAR SIDE WINDOW ANTENNA SEDAN STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (IF EQUIPPED) STEERING WHEEL CONTROL UNIT WHT WIRE YEL WIRE
