Audi S4 B7 (2004-2008) right temperature flap actuator/ potentiometer Wiring diagram
This page shows the only wiring diagram for the component.right temperature flap actuator/ potentiometer, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right temperature flap actuator/ potentiometer (1 of 1)
AIR QUALITY SENSOR (IF EQUIPPED)
B+ B-
BACK PRESSURE FLAP MOTOR, POSITION SENSOR
BLK/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CENTRAL AIR FLAP MOTOR/ POSITION SENSOR
DEFROSTER FLAP MOTOR, POSITION SENSOR
EVAPORATOR VENT TEMPERATURE SENSOR
FRESH AIR INTAKE DUCT TEMPERATURE SENSOR
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATED FRONT WINDOW
HIGH PRESSURE SENSOR
LEFT FOOTWELL VENT TEMPERATURE SENSOR
LEFT TEMPERATURE FLAP ACTUATOR/ POTENTIOMETER
RECIRCULATION FLAP MOTOR, POSITION SENSOR
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FOOTWELL VENT TEMPERATURE SENSOR
RIGHT TEMPERATURE FLAP ACTUATOR/ POTENTIOMETER
SUNLIGHT PHOTO SENSOR
WHT/GRN WIRE
WHT/YEL WIRE
WINDSHIELD HEATING VOLTAGE CONVERTER
Go to component: -> Automatic a/c circuit (2 of 3) -> RIGHT TEMPERATURE FLAP ACTUATOR/ POTENTIOMETER
