Audi S4 B7 (2004-2008) right rear window breakage sensor Wiring diagram

This page shows the only wiring diagram for the component.right rear window breakage sensor, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right rear window breakage sensor (1 of 1)

Wiring diagram right rear window breakage sensor for Audi S4 B7 (2004-2008)

Get access

BLK WIRE BRN WIRE BRN/RED WIRE CLIMATRONIC CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE FUSE 26 FUSE PANEL HOT AT ALL TIMES LEFT ANTENNA MODULE LEFT REAR WINDOW BREAKAGE SENSOR NCA WIRE REAR WINDOW DEFOGGER RELAY REAR WINDOW DEFOGGER W/ WINDOW ANTENNA RIGHT REAR WINDOW BREAKAGE SENSOR W/ ALARM SYSTEM WHT/VIO WIRE WHT/YEL WIRE WINDSHIELD ANTENNA SUPPRESSION FILTER

Go to component: -> Rear defogger circuit, avant -> RIGHT REAR WINDOW BREAKAGE SENSOR
