Audi S4 B7 (2004-2008) right compartment cover locked switch 1 Wiring diagram

This page shows the only wiring diagram for the component.right compartment cover locked switch 1, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right compartment cover locked switch 1 (1 of 1)

Wiring diagram right compartment cover locked switch 1 for Audi S4 B7 (2004-2008)

Get access

3-PIN RELAY CARRIER AMPLIFIER BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPART -MENT COVER OPEN POSITION SWITCH CONVERTIBLE TOP CLOSED POSITION SWITCH CONVERTIBLE TOP COMPARTMENT ENCLOSURE POSITION SWITCH CONVERTIBLE TOP FRONT LOCK SWITCH CONVERTIBLE TOP FUSE CONVERTIBLE TOP HYDRAULIC PUMP CONVERTIBLE TOP HYDRAULIC PUMP RELAY CONVERTIBLE TOP HYDRAULIC PUMP RELAY 2 CONVERTIBLE TOP OPEN POSITION SWITCH CONVERTIBLE TOP OPERATION HYDRAULIC UNIT CONVERTIBLE TOP RIGHT LOCK SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT CONVERTIBLE TOP COVER COMPARTMENT COVER SWITCH NCA WIRE POWER CONVERTIBLE TOP VALVE 1 POWER CONVERTIBLE TOP VALVE 2 POWER CONVERTIBLE TOP VALVE 3 RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RIGHT COMPARTMENT COVER LOCKED SWITCH 1 VIO WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component: -> Convertible top circuit (2 of 2) -> RIGHT COMPARTMENT COVER LOCKED SWITCH 1
