Audi S4 B7 (2004-2008) rear lid unlock motor Wiring diagram

This page shows the only wiring diagram for the component.rear lid unlock motor, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram rear lid unlock motor (1 of 1)

Wiring diagram rear lid unlock motor for Audi S4 B7 (2004-2008)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUEL TANK LID UNLOCK MOTOR GRN WIRE GRY WIRE ORG/ WIRE REAR LID LOCK CYLINDER SWITCH REAR LID REMOTE CONTROL RELEASE SWITCH REAR LID UNLOCK MOTOR RED WIRE REMOTE POWER FUEL TANK LID RELEASE INFO NOT AVAILABLE TRUNK LID ALARM SWITCH VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Trunk & fuel door release circuit -> REAR LID UNLOCK MOTOR
