Audi S4 B7 (2004-2008) passenger's seat inclination adjustment motor Wiring diagram

This page shows the only wiring diagram for the component.passenger's seat inclination adjustment motor, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger's seat inclination adjustment motor (1 of 1)

Wiring diagram passenger's seat inclination adjustment motor for Audi S4 B7 (2004-2008)

Get access

4-PIN RELAY CARRIER BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR DRIVER'S POWER SEAT SWITCH DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR DRIVER'S SEAT SEATBACK ADJUSTMENT MOTOR HOT AT ALL TIMES LUMBAR CURV- ATURE LUMBAR HEIGHT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR PASSENGER'S POWER SEAT SWITCH PASSENGER'S SEAT FORE/AFT ADJUSTMENT MOTOR PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR PASSENGER'S SEAT INCLINATION ADJUSTMENT MOTOR PASSENGER'S SEAT SEATBACK ADJUSTMENT MOTOR POWER SEAT FUSE 45 RED WIRE WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> PASSENGER'S SEAT INCLINATION ADJUSTMENT MOTOR
