Audi S4 B7 (2004-2008) passenger side door wiring diagram
This page shows the only wiring diagram for the component.passenger side door, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passenger side door wiring diagram (1 of 1)
BLU WIRE
BRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CONTROL MODULE
DRIVER DOOR CONTROL MODULE
DRIVER SIDE CENTRAL LOCKING UNIT (DOOR CONTACT SWITCH)
DRIVER SIDE DOOR WARNING LIGHT
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LEFT FRONT ENTRY LIGHT
LEFT REAR CENTRAL LOCKING UNIT (DOOR CONTACT SWITCH)
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR WARNING LIGHT
LEFT REAR ENTRY LIGHT
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER COMPARTMENT MONITORING SWITCH
PASSENGER SIDE CENTRAL LOCKING UNIT (DOOR CONTACT SWITCH)
PASSENGER SIDE DOOR
PASSENGER SIDE DOOR WARNING LIGHT
POWER WINDOWS, MIRRORS, DOOR LOCKS SYSTEMS, INSTRUMENT ILLUMINATION CIRCUIT
RED WIRE
RED/VIO WIRE
RIGHT FRONT ENTRY LIGHT
RIGHT REAR CENTRAL LOCKING UNIT (DOOR CONTACT SWITCH)
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR WARNING LIGHT
RIGHT REAR ENTRY LIGHT
RIGHT REAR ENTRY LIGHT RIGHT REAR DOOR WARNING LIGHT
VIO WIRE
W/ REAR POWER WINDOWS
W/O REAR POWER WINDOWS
YEL WIRE
Go to component -> Courtesy lamps circuit, sedan (2 of 2) -> PASSENGER SIDE DOOR
