Audi S4 B7 (2004-2008) instrument cluster control module Wiring diagram

AVANT BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 13 FUSE 37 FUSE 36 FUSE 15 FUSE HOLDER GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE HEADLIGHT WASHER PUMP WINDSHIELD WIPER MOTOR HOT AT ALL TIMES HOT AT ALL TIMES FUSE STRIP (MAIN FUSE) FUSE 88 HOT W/ LOAD REDUCTION RELAY ENERGIZED IGNITION/ STARTER SWITCH INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER SYSTEM LOCK OFF NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE REAR WINDSHIELD WIPER MOTOR (AVANT) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE W/ AVANT W/ CONVERTIBLE WHT WIRE WINDSHIELD WASHER FLUID LEVEL WARNING SWITCH WINDSHIELD WASHER PUMP WINDSHIELD WIPER/WASHER SWITCH YEL WIRE YEL/BLK WIRE
