Audi S4 B7 (2004-2008) heated seat temp sensor Wiring diagrams

A/C CONTROL HEAD AIR CONDITIONING SYSTEM AIRBAG SPIRAL SPRING/ RETURN SPRING W/ SLIP RING BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST HEATING ELEMENT DRIVER'S SEAT HEATER FUSE 44 FUSE HOLDER GRN WIRE HEATED SEAT TEMP SENSOR HEATED STEERING WHEEL (IF EQUIPPED) HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER'S BACKREST HEATING ELEMENT PASSENGER'S SEAT HEATER RED WIRE RED/WHT WIRE SEAT HEATER SIDE BOLSTER HEATER STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (IF EQUIPPED) STEERING WHEEL CONTROL UNIT WHT WIRE YEL WIRE YEL/BLU WIRE

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE FUSE 44 FUSE 5 FUSE HOLDER GRN WIRE GRY/BLU WIRE HEATED SEAT TEMP SENSOR HOT AT ALL TIMES HOT IN RUN OR START LEFT REAR BACKREST HEATING ELEMENT LEFT REAR HEATED SEAT CONTROL MODULE LEFT REAR SEAT HEATER NCA WIRE RED WIRE RED/WHT WIRE RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR HEATED SEAT CONTROL MODULE RIGHT REAR SEAT HEATER SEAT HEATER SEAT OCCUPIED SENSOR WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE
