Audi S4 B7 (2004-2008) front interior light Wiring diagrams

This page contains all the electrical diagrams for the component. front interior light, in which he is found in the car Audi S4 B7 (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram front interior light (1 of 2)

Wiring diagram front interior light for Audi S4 B7 (2004-2008)

Get access

AUTOMATIC DAY/NIGHT INTERIOR MIRROR BLK WIRE BLK/BLU WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE DRIVER SIDE DOOR CONTROL MODULE FRONT INTERIOR LIGHT LIGHT RECOGNITION SENSOR LIGHT SWITCH PASSENGER SIDE DOOR CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/VIO WIRE

Go to component: -> Automatic day/night mirror circuit -> FRONT INTERIOR LIGHT

Wiring diagram front interior light (2 of 2)

Wiring diagram front interior light for Audi S4 B7 (2004-2008)

Get access

ABS CONTROL MODULE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE FRONT INTERIOR LIGHT FUSE 30 FUSE HOLDER HOT AT ALL TIMES NCA WIRE POWER SUNROOF CONTROL MODULE POWER WINDOWS SYSTEM RED WIRE RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE SUNROOF SWITCH WHT WIRE WHT/BLU WIRE

Go to component: -> Sunroof circuit -> FRONT INTERIOR LIGHT
