Audi S4 B7 (2004-2008) driver door window regulator switches Wiring diagram
This page shows the only wiring diagram for the component.driver door window regulator switches, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver door window regulator switches (1 of 1)
BLU WIRE
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR WINDOW REGULATOR SWITCHES
DRIVER SIDE DOOR CONTROL MODULE
DRIVER SIDE DOOR OPENER LIGHTING
DRIVER SIDE INTERIOR LOCK SWITCH
DRIVER'S SEAT MEMORY PROGRAM SWITCH
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR OPENER LIGHT
LEFT REAR WINDOW SWITCH
MIRROR ADJUSTMENT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER COMPARTMENT MONITORING SWITCH
PASSENGER DOOR CONTROL MODULE
PASSENGER DOOR WINDOW REGULATOR SWITCH
PASSENGER SIDE DOOR OPENER LIGHTING
PASSENGER SIDE INTERIOR LOCK SWITCH
POWER WINDOWS, DOOR LOCKS, COURTESY LIGHTS CIRCUIT
POWER WINDOWS, MIRRORS, DOOR LOCKS SYSTEMS, COURTESY LAMPS CIRCUIT
REAR LID RELEASE SWITCH
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR OPENER LIGHT
RIGHT REAR WINDOW SWITCH
Go to component: -> Instrument illumination circuit (2 of 2) -> DRIVER DOOR WINDOW REGULATOR SWITCHES
