Audi S4 B7 (2004-2008) compart -ment cover open position switch Wiring diagram
This page shows the only wiring diagram for the component.compart -ment cover open position switch, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram compart -ment cover open position switch (1 of 1)
3-PIN RELAY CARRIER
AMPLIFIER
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPART -MENT COVER OPEN POSITION SWITCH
CONVERTIBLE TOP CLOSED POSITION SWITCH
CONVERTIBLE TOP COMPARTMENT ENCLOSURE POSITION SWITCH
CONVERTIBLE TOP FRONT LOCK SWITCH
CONVERTIBLE TOP FUSE
CONVERTIBLE TOP HYDRAULIC PUMP
CONVERTIBLE TOP HYDRAULIC PUMP RELAY
CONVERTIBLE TOP HYDRAULIC PUMP RELAY 2
CONVERTIBLE TOP OPEN POSITION SWITCH
CONVERTIBLE TOP OPERATION HYDRAULIC UNIT
CONVERTIBLE TOP RIGHT LOCK SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT CONVERTIBLE TOP COVER COMPARTMENT COVER SWITCH
NCA WIRE
POWER CONVERTIBLE TOP VALVE 1
POWER CONVERTIBLE TOP VALVE 2
POWER CONVERTIBLE TOP VALVE 3
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RIGHT COMPARTMENT COVER LOCKED SWITCH 1
VIO WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component: -> Convertible top circuit (2 of 2) -> COMPART -MENT COVER OPEN POSITION SWITCH
