Audi S4 B7 (2004-2008) alarm horn Wiring diagram
This page shows the only wiring diagram for the component.alarm horn, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram alarm horn (1 of 1)
ALARM HORN
ANTENNA SUPPRESSION FILTER
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
EXTERIOR LIGHTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
FRONT HOOD SWITCH
FUSE 24
FUSE 38
FUSE HOLDER
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT REAR BROKEN WINDOW GLASS SENSOR
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARKING BRAKE WARNING LIGHT SWITCH
REAR WINDOW DEFOGGER (W/ RADIO)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT REAR BROKEN WINDOW GLASS SENSOR
TRUNK LID ALARM SWITCH (AVANT) TRUNK LOCK/ ALARM/CENTRAL LOCKING SWITCH
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Anti-theft circuit -> ALARM HORN
