Audi S4 B7 (2004-2008) +2 -1 left front bass speaker Wiring diagram
This page shows the only wiring diagram for the component.+2 -1 left front bass speaker, which is found in the car Audi S4 B7 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +2 -1 left front bass speaker (1 of 1)
+2 -1 LEFT FRONT BASS SPEAKER
+2 -1 RIGHT FRONT BASS SPEAKER
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
CD CHANGER UNIT
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
FUSE 39
FUSE HOLDER
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE LOUDSPEAKER
LEFT FRONT MIDRANGE SPEAKER
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RED/BLU WIRE
RIGHT FRONT MIDRANGE SPEAKER
ROOF ANTENNA
SATELLITE RADIO
TELEPHONE/ TELEMATIC CONTROL MODULE 10 31
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ SATELLITE RADIO
W/O SATELLITE RADIO
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Symphony ii circuit, with amplifier (1 of 2) -> +2 -1 LEFT FRONT BASS SPEAKER
