Audi S3 8Y (2020-2024) locking ind lamp wiring diagram
This page shows the only wiring diagram for the component.locking ind lamp, which is found in the car Audi S3 8Y (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
locking ind lamp wiring diagram (1 of 1)
ACCESS/START AUTHORIZATION BUTTON
ACCESS/START AUTHORIZATION CONTROL MODULE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COURTESY LAMPS CIRCUIT
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER INTERIOR LOCKING BUTTON
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
EXTERIOR REAR VIEW MIRROR ADJUSTER
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR POWER WINDOW SWITCH
FRONT PASSENGER INTERIOR LOCKING BUTTON
FUEL FILLER DOOR RELEASE BUTTON
FUSE 26
FUSE PANEL C
GRN WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LOCKING IND LAMP
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER SIDE REAR DOOR CONTROL HEAD
PASSENGER SIDE REAR DOOR CONTROL MODULE
POWER WINDOW BUTTON
REAR LID REMOTE RELEASE BUTTON
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RIGHT REAR DOOR COUPLING POINT
WHT/YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> LOCKING IND LAMP
