Audi S3 8Y (2020-2024) front passenger backrest coupling point wiring diagram
This page shows the only wiring diagram for the component.front passenger backrest coupling point, which is found in the car Audi S3 8Y (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front passenger backrest coupling point wiring diagram (1 of 1)
BLK/VIO WIRE
DRIVER MULTI- CONTOUR SEAT CONTROL MODULE
DRIVER SEAT BACKREST COUPLING POINT
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FRONT PASSENGER BACKREST COUPLING POINT
FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE
GARAGE DOOR OPENER CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HEATING, AIR CONDITIONING CONTROL MODULE
INSTRUMENT CLUSTER
LEFT COUPLING POINT IN INTERIOR
LEFT FRONT SEAT COUPLING STATION
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
RAIN/LIGHT RECOGNITION SENSOR
REAR LID CONTROL MODULE
RED WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT SEAT COUPLING STATION
TOWING RECOGNITION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/RED WIRE
VIO/WHT WIRE
W/ TRAILER SETUP
W/O TRAILER SETUP
WHT WIRE
Go to component -> Computer data lines circuit (6 of 7) -> FRONT PASSENGER BACKREST COUPLING POINT
