Audi S3 8Y (2020-2024) computer data lines system Wiring diagrams

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 59 FUSE PANEL C HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED ORG/BRN WIRE RED WIRE RED/GRN WIRE STRUCTURE BORNE SOUND ACTUATOR STRUCTURE BORNE SOUND CONTROL MODULE YEL WIRE

BLK WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT COUPLING STATION IN RIGHT FRONT SEAT FRONT A/C DISPLAY CONTROL HEAD FUSE 7 FUSE PANEL C GRN WIRE GRN/BRN WIRE HEATED DRIVER SEAT INDICATOR LAMP HEATED FRONT PASSENGER SEAT INDICATOR LAMP HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION LEFT FRONT SEAT EXTENSION HEATING ELEMENT LEFT FRONT SEAT HEATED BACKREST LEFT FRONT SEAT HEATING ELEMENT LEFT FRONT SEAT TEMPERATURE SENSOR LEFT SEAT HEATING BUTTON ORG/BRN WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT SEAT COUPLING STATION RIGHT FRONT SEAT EXTENSION HEATING ELEMENT RIGHT FRONT SEAT HEATED BACKREST RIGHT FRONT SEAT HEATING ELEMENT RIGHT FRONT SEAT TEMPERATURE SENSOR RIGHT SEAT HEATING BUTTON SEAT OCCUPANT DETECTION SYSTEM CONTROL MODULE VIO/WHT WIRE W/ SEAT DEPTH ADJUSTER W/ SEAT DEPTH ADJUSTMENT W/O SEAT DEPTH ADJUSTER WHT WIRE WHT/VIO WIRE WHT/YEL WIRE

BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 45 FUSE PANEL C GRN/WHT WIRE HEATED STEERING WHEEL HEATED STEERING WHEEL SENSOR HOT AT ALL TIMES LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL NCA WIRE RED/YEL WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE VIO/WHT WIRE

AUTOMATIC DIMMING BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE INDICATOR LAMP MEMORY SEAT FOLDING MOTOR FUSE 9 FUSE PANEL C GRN WIRE GRN/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEATER (IF EQUIPPED) HORIZONTAL POSITION SENSOR HOT AT ALL TIMES LANE CHANGE ASSISTANCE WARNING LAMP LEFT FRONT DOOR COUPLING POINT MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON MIRROR ADJUSTMENT MOTOR MIRROR ADJUSTMENT MOTOR 2 NAVIGATION SYSTEM ORG/BRN WIRE PNK WIRE RED WIRE RED/VIO WIRE SEAT POSITION MEMORY BUTTON TURN SIGNAL BULB VERTICAL POSITION SENSOR W/ POWER FOLDING EXTERIOR REAR VIEW MIRRORS W/O POWER FOLDING EXTERIOR REAR VIEW MIRRORS WHT WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER DOOR CONTROL MODULE DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT FORWARD/ BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/ BACK ADJUSTMENT SENSOR DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SENSOR DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SEAT TILT ADJUSTMENT SENSOR DRIVER SIDE INDICATOR LAMP MEMORY SEAT FUSE 9 FUSE CARRIER 1 FUSE PANEL C GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT LEFT FRONT SEAT COUPLING STATION MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/VIO WIRE SEAT POSITION MEMORY BUTTON VIO WIRE W/O POWER LUMBAR SUPPORT ADJUSTMENT WHT WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE

BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER MULTI- CONTOUR SEAT CONTROL MODULE DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT SWITCH MODULE FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT SWITCH MODULE FUSE 23 FUSE 33 FUSE PANEL C GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION RED/BRN WIRE RED/WHT WIRE RIGHT FRONT SEAT COUPLING STATION VIO/WHT WIRE

BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER POWER WINDOW BUTTON DRIVER SIDE REAR DOOR CONTROL HEAD DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR POWER WINDOW BUTTON DRIVER SIDE REAR WINDOW REGULATOR MOTOR DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE DRIVER WINDOW REGULATOR MOTOR FRONT PASSENGER POWER WINDOW BUTTON FUSE 9 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT CHILD SAFETY LOCK BUTTON LEFT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP LEFT FRONT DOOR COUPLING POINT LEFT REAR DOOR COUPLING POINT ORG/BRN WIRE PASSENGER SIDE REAR POWER WINDOW BUTTON RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT CHILD SAFETY LOCK BUTTON RIGHT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP W/ LEFT REAR DOOR CONTROL MODULE W/ MANUAL CHILD SAFETY LOCK W/O LEFT REAR DOOR CONTROL MODULE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR POWER WINDOW SWITCH FRONT PASSENGER WINDOW REGULATOR MOTOR FUSE 26 FUSE PANEL C GRN WIRE GRN/WHT WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES ORG/BRN WIRE PASSENGER SIDE REAR DOOR CONTROL HEAD PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR POWER WINDOW BUTTON PASSENGER SIDE REAR WINDOW REGULATOR MOTOR PASSENGER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT REAR DOOR COUPLING POINT W/ AMBIENT LIGHTING W/ MANUAL CHILD SAFETY LOCK W/ RIGHT REAR DOOR CONTROL MODULE W/O RIGHT REAR DOOR CONTROL MODULE

BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 21 FUSE 37 FUSE 6 FUSE 9 FUSE PANEL C GRN WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER ORG/BRN WIRE REAR LID CLOSING AID REAR LID CLOSING AID MOTOR REAR LID CONTROL MODULE REAR LID DRIVE UNIT REAR LID DRIVE UNIT 2 REAR LID MOTOR 1 REAR LID MOTOR 1 SENSOR REAR LID MOTOR 1 SENSOR 2 REAR LID MOTOR 2 REAR LID MOTOR 2 SENSOR REAR LID MOTOR 2 SENSOR 2 REAR LID WARNING BUZZER RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/YEL WIRE WHT/RED WIRE YEL/BLK WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE FUEL FILLER DOOR LOCK MOTOR GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/WHT WIRE LEFT FRONT DOOR COUPLING POINT LUGGAGE COMPARTMENT REAR LID LOCK BUTTON ORG/BRN WIRE POWER REAR LID OPENING CONTROL MODULE POWER REAR LID OPENING SENSOR POWER REAR LID OPENING SENSOR 2 REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR LID CONTROL HEAD REAR LID HANDLE RELEASE BUTTON REAR LID LOCK UNIT (CENTER OF REAR LID) REAR LID LOCKING MECHANISM BUTTON REAR LID REMOTE RELEASE BUTTON RED/BLU WIRE RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR BUMPER COUPLING POINT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE W/ LED TAIL LAMPS WHT WIRE YEL/BLK WIRE
