Trunk & fuel door release circuit for Audi S3 8V facelift (2016-2020)
Trunk & fuel door release circuit
2.0L TURBO
BLK/GRN WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
FUEL FILLER DOOR LOCK MOTOR
FUSE 25
FUSE 31
FUSE PANEL C
GRN/BLK WIRE
GRN/WHT WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID ALARM SWITCH/REAR LID CENTRAL LOCKING SYSTEM MOTOR
REAR LID HANDLE RELEASE BUTTON
REAR LID UNLOCK SWITCH
RED/GRY WIRE
RED/VIO WIRE
SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLU WIRE
VIO/RED WIRE
VIO/WHT WIRE
W/ ACCESS/START AUTHORIZATION SYSTEM W/O ACCESS/START AUTHORIZATION SYSTEM
WHT WIRE
