Car Wiring Diagrams for Power windows circuit for Audi S3 8V facelift (2016-2020)

4 DOOR 4 DOOR 5 DOOR 5 DOOR BLU/BLK WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CENTRAL WINDOW REGULATOR SWITCH DRIVER DOOR CONTROL MODULE DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER POWER WINDOW BUTTON DRIVER SIDE REAR CHILD SAFETY LOCK BUTTON DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR POWER WINDOW BUTTON DRIVER SIDE REAR WINDOW REGULATOR MOTOR DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE DRIVER WINDOW LOWERING MICROSWITCH DRIVER WINDOW REGULATOR MOTOR FRONT PASSENGER POWER WINDOW BUTTON FUSE 25 FUSE 39 FUSE PANEL C GRN/BLK WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE REAR CHILD SAFETY LOCK BUTTON PASSENGER SIDE REAR POWER WINDOW BUTTON RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SWITCH ILLUMINATION VIO/GRY WIRE W/ AUXILIARY LAMPS YEL WIRE YEL/GRN WIRE YEL/RED WIRE

4 DOOR 5 DOOR BLU/BLK WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER POWER WINDOW BUTTON FRONT PASSENGER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE FRONT PASSENGER WINDOW LOWERING MICROSWITCH FRONT PASSENGER WINDOW REGULATOR MOTOR GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR POWER WINDOW BUTTON PASSENGER SIDE REAR WINDOW REGULATOR MOTOR PASSENGER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO/GRY WIRE VIO/YEL WIRE W/ AUXILIARY LAMPS
