Audi S3 8V facelift (2016-2020) mirror adjustment switch assembly Wiring diagram
This page shows the only wiring diagram for the component.mirror adjustment switch assembly, which is found in the car Audi S3 8V facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror adjustment switch assembly (1 of 1)
AUTOMATIC DAY/NIGHT MIRROR CIRCUIT
AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR MIRROR ASSEMBLY
EXTERIOR REAR VIEW MIRROR FOLDING MOTOR
FOLDING MIRROR ADJUSTMENT SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR MIRROR ASSEMBLY
FUSE 25
FUSE 39
FUSE PANEL C
GRN WIRE
GRY/YEL WIRE
HEATED EXTERIOR REAR VIEW MIRROR/ EXTERIOR REAR VIEW MIRROR TURN SIGNAL BULB
HOT AT ALL TIMES
MIRROR ADJUSTING SWITCH
MIRROR ADJUSTMENT MOTOR
MIRROR ADJUSTMENT MOTOR 2
MIRROR ADJUSTMENT SWITCH ASSEMBLY
MIRROR SELECTOR SWITCH
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR VIEW MIRROR)
RED/GRN WIRE
RED/VIO WIRE
Go to component -> Power mirrors circuit -> MIRROR ADJUSTMENT SWITCH ASSEMBLY
