Audi S3 8V facelift (2016-2020) information electronics control module 1, center switch module Wiring diagram
This page shows the only wiring diagram for the component.information electronics control module 1, center switch module, which is found in the car Audi S3 8V facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram information electronics control module 1, center switch module (1 of 1)
4 DOOR
ABS CONTROL MODULE
ACCESS/START AUTHORIZATION CONTROL MODULE
BLK WIRE
BRN WIRE
CIGARETTE LIGHTER (W/ SMOKING PACKAGE), SELECTOR LEVER,
DRIVER THORAX AIRBAG IGNITER, TERMINAL 15 POWER SUPPLY RELAY,
FRONT INTERIOR LAMP, HUMIDITY SENSOR, RAIN/LIGHT RECOGNITION SENSOR
HUMIDITY SENSOR/ RAIN/LIGHT RECOGNITION SENSOR
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION START BUTTON ILLUMINATION BULB, ACCESS/START AUTHORIZATION BUTTON,
INFORMATION ELECTRONICS CONTROL MODULE 1, CENTER SWITCH MODULE
LIGHT SWITCH
REAR VIEW MIRROR)
SOCKETS RELAY
USB DISTRIBUTOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
Go to component -> Ground distribution circuit (2 of 4) -> INFORMATION ELECTRONICS CONTROL MODULE 1, CENTER SWITCH MODULE
