Audi S3 8V facelift (2016-2020) ground distribution system Wiring diagram
This page shows the only wiring diagram for the component.ground distribution system, which is found in the car Audi S3 8V facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground distribution system (1 of 1)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR MIRROR ASSEMBLY
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR MIRROR ASSEMBLY
FUSE 25
FUSE 39
FUSE PANEL C
GROUND DISTRIBUTION SYSTEM
HEATED EXTERIOR REAR VIEW MIRROR
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/GRN WIRE
RED/VIO WIRE
W/O ACCESS/START AUTHORIZATION SYSTEM W/ ACCESS/START AUTHORIZATION SYSTEM
Go to component -> Heated mirrors circuit -> GROUND DISTRIBUTION SYSTEM
