Audi S3 8V facelift (2016-2020) digital sound system control module Wiring diagrams
This page contains all the electrical diagrams for the component. digital sound system control module, in which he is found in the car Audi S3 8V facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram digital sound system control module (1 of 3)
ACCESS/START AUTHORIZATION CONTROL MODULE
BLK/VIO WIRE
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CLIMATRONIC CONTROL MODULE
CONVERTIBLE TOP CONTROL MODULE
DIAGNOSTIC CONNECTOR
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVER DOOR CONTROL MODULE
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
FUSE 35
FUSE 5
FUSE 8
FUSE PANEL C
GRN/VIO WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER (W/ MULTI-FUNCTION DISPLAY)
INSTRUMENT CLUSTER (W/O MULTI-FUNCTION DISPLAY)
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/RED WIRE
ORG/VIO WIRE
PASSENGER SIDE REAR DOOR CONTROL MODULE
PASSENGER SIDE WINDOW REGULATOR MOTOR CONTROL MODULE
RED/BLU WIRE
STEERING COLUMN ELECTRONICS CONTROL MODULE
TV TUNER
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/O HEATED STEERING WHEEL W/ HEATED STEERING WHEEL
W/O START/STOP SYSTEM
Go to component -> Computer data lines circuit (1 of 4) -> DIGITAL SOUND SYSTEM CONTROL MODULE
Wiring diagram digital sound system control module (2 of 3)
Go to component -> Most data bus circuit -> DIGITAL SOUND SYSTEM CONTROL MODULE
Wiring diagram digital sound system control module (3 of 3)
2.0L TURBO CNTC, DJJA
2.0L TURBO CZRA, 2.5L TURBO
2.0L TURBO, 1.4L TURBO
ABS CONTROL MODULE
ACCESS/ START AUTHORIZATION CONTROL MODULE
ALL- WHEEL DRIVE CONTROL MODULE
BLU WIRE
BLU/GRY WIRE
CONVERTIBLE TOP HYDRAULIC MODULE
CONVERTIBLE TOP HYDRAULIC PUMP RELAY
CONVERTIBLE TOP HYDRAULIC PUMP RELAY 2
DIGITAL SOUND SYSTEM CONTROL MODULE
DUAL-CLUTCH TRANSMISSION MECHATRONIC
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
ELECTRONICS BOX)
FROM FUSE 25 (DIAGRAM 7 OF 7)
FROM FUSE 4 (DIAGRAM 1 OF 7)
FROM LUGGAGE COMPARTMENT MAIN FUSE PANEL (DIAGRAM 1 OF 7)
FUSE 1
FUSE 13
FUSE 15
FUSE 17
FUSE 18
FUSE 2
FUSE 24
FUSE 26
FUSE 27
FUSE 3
FUSE 43
FUSE 44
FUSE 5
FUSE 6
FUSE PANEL A
FUSE PANEL B
FUSE PANEL C
GRY/RED WIRE
HYBRID EXCEPT HYBRID W/ MULTI-FUNCTION DISPLAY W/O MULTI-FUNCTION DISPLAY
INSTRUMENT CLUSTER
NCA WIRE
RADIATOR FAN CONTROL MODULE
REAR VIEW CAMERA SYSTEM CONTROL MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
TO FUSE 15 (DIAGRAM 3 OF 7)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLK WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (2 of 7) -> DIGITAL SOUND SYSTEM CONTROL MODULE
