Audi S3 8V facelift (2016-2020) brn Wiring diagrams

This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi S3 8V facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram brn (111 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (111 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER CENTRAL LOCKING LOCK UNIT DRIVER DOOR CONTACT SWITCH DRIVER SIDE DOOR SPEAKER TRIM LAMP FIBER OPTIC CABLE FOR LEFT FRONT SILL PANEL AMBIENT LIGHTING FIBER OPTIC CABLE FOR RIGHT FRONT SILL PANEL AMBIENT LIGHTING FRONT PASSENGER CENTRAL LOCKING LOCK UNIT FRONT PASSENGER DOOR CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR WARNING LAMP FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER POWER WINDOW BUTTON FRONT PASSENGER SIDE REAR DOOR AMBIENT LIGHT LAMP FUSE 25 FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE GRY/VIO WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE DOOR AMBIENT LIGHTING LAMP PASSENGER SIDE DOOR SPEAKER TRIM LAMP PASSENGER SIDE ENTRY LAMP PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION BULB RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE VIO WIRE VIO/GRY WIRE VIO/YEL WIRE W/ AUXILIARY LAMPS WHT WIRE

Go to component -> Courtesy lamps circuit (3 of 5) -> BRN WIRE

Wiring diagram brn (112 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (112 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER DOOR WARNING LAMP DRIVER INTERIOR LOCKING BUTTON DRIVER READING LAMP DRIVER READING LAMP BUTTON DRIVER SIDE DOOR AMBIENT LIGHTING LAMP DRIVER SIDE ENTRY LAMP DRIVER SIDE INTERIOR DOOR HANDLE ILLUMINATION BULB DRIVER SIDE REAR DOOR AMBIENT LIGHT LAMP FRONT INTERIOR LAMP FRONT INTERIOR LAMP (2 DOOR) FRONT INTERIOR LAMP BUTTON FRONT PASSENGER READING LAMP FRONT PASSENGER READING LAMP BUTTON GLOVE COMPARTMENT LAMP GLOVE COMPARTMENT LAMP SWITCH GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY/VIO WIRE GRY/WHT WIRE INSTRUMENT ILLUMINATION CIRCUIT INTERIOR MONITORING, VEHICLE INCLINATION DEACTIVATION BUTTON MIRROR ADJUSTING SWITCH MIRRORS SYSTEM ORG/BRN WIRE ORG/GRN WIRE REAR LID UNLOCK SWITCH RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE SWITCH ILLUMINATION BULB VIO WIRE VIO/GRY WIRE VIO/WHT WIRE W/ AMBIENT LIGHTING W/O AMBIENT LIGHTING W/ AUXILIARY LAMPS W/ INTERIOR MONITORING WHT WIRE

Go to component -> Courtesy lamps circuit (4 of 5) -> BRN WIRE

Wiring diagram brn (113 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (113 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR MIRROR ASSEMBLY FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER EXTERIOR MIRROR ASSEMBLY FUSE 25 FUSE 39 FUSE PANEL C GROUND DISTRIBUTION SYSTEM HEATED EXTERIOR REAR VIEW MIRROR HOT AT ALL TIMES NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RED/GRN WIRE RED/VIO WIRE W/O ACCESS/START AUTHORIZATION SYSTEM W/ ACCESS/START AUTHORIZATION SYSTEM

Go to component -> Heated mirrors circuit -> BRN WIRE

Wiring diagram brn (114 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (114 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

AUXILIARY BLU/BLK WIRE BRN WIRE CENTER INSTRUMENT PANEL SWITCH MODULE COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP OPERATION SWITCH COURTESY LAMPS CIRCUIT CUP HOLDER AMBIENT LIGHTING LAMP DRIVING PROFILE SELECTION INDICATOR LAMP ELECTRO- MECHANICAL PARKING BRAKE BUTTON EMERGENCY FLASHER INDICATOR LAMP FRONT INTERIOR LAMP FRONT ROOF MODULE FUSE 42 FUSE 8 FUSE PANEL C GRN WIRE GRY WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LAMPS) LIGHT SWITCH ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR INTERIOR LOCKING BUTTON PASSENGER SIDE REAR POWER WINDOW BUTTON PUSH BUTTON ILLUMINATION BULB RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE SWITCH ILLUMINATION BULB VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE VIO/GRY WIRE VIO/YEL WIRE W/ ABS W/O ABS WHT WIRE

Go to component -> Instrument illumination circuit (1 of 3) -> BRN WIRE

Wiring diagram brn (115 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (115 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

4 DOOR 5 DOOR BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COURTESY LAMPS CIRCUIT DRIVER DOOR CONTROL MODULE DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER INTERIOR LOCKING BUTTON FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER POWER WINDOW BUTTON GRN WIRE GRN/BLK WIRE GRN/YEL WIRE INTERIOR MONITORING, VEHICLE INCLINATION DEACTIVATION BUTTON ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP RED/GRN WIRE RED/VIO WIRE SWITCH ILLUMINATION BULB VIO WIRE VIO/GRY WIRE VIO/YEL WIRE W/ ACCESS/START AUTHORIZATION SYSTEM W/O ACCESS/START AUTHORIZATION SYSTEM W/ AUXILIARY LAMPS W/ INTERIOR MONITORING YEL WIRE

Go to component -> Instrument illumination circuit (3 of 3) -> BRN WIRE

Wiring diagram brn (116 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (116 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

ANTENNA ANTENNA AMPLIFIER ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER 3 RADIO ANTENNA 2 BLK WIRE BLU/BLK WIRE BLU/GRY WIRE BRN WIRE CELLULAR TELEPHONE AMPLIFIER FUSE 16 FUSE PANEL C GPS ANTENNA HOT AT ALL TIMES LEFT REAR TREBLE SPEAKER NCA WIRE RADIO ANTENNA RED/BLK WIRE RED/YEL WIRE ROOF ANTENNA SATELLITE TUNER ANTENNA SEDAN, SPORTBACK SPORTBACK TELEPHONE ANTENNA TELEPHONE BASEPLATE VIO/WHT WIRE

Go to component -> Navigation circuit, w/ amplifier (3 of 5) -> BRN WIRE

Wiring diagram brn (117 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (117 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTION, USB CONNECTION BASEPLATE FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 10 FUSE 4 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER LTE ANTENNA 1 LTE ANTENNA 2 MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE SEDAN, SPORTBACK SOUND SYSTEMS TELEPHONE ANTENNA VIO WIRE VIO/BLK WIRE W/ EXTERNAL MULTIMEDIA DEVICE CONNECTION, ELECTRICAL INTERFACE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Navigation circuit, w/o amplifier (1 of 5) -> BRN WIRE

Wiring diagram brn (118 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (118 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

ANTENNA AMPLIFIER 4 BLK WIRE BLU WIRE BRN WIRE DIGITAL RADIO ANTENNA GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE LEFT FRONT BASS SPEAKER LEFT FRONT TREBLE SPEAKER NCA WIRE ORG/ WIRE RED/BLK WIRE RED/YEL WIRE RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER SATELLITE TUNER ANTENNA SEDAN, SPORTBACK VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Navigation circuit, w/o amplifier (2 of 5) -> BRN WIRE

Wiring diagram brn (119 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (119 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

BLK/RED WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER SWITCH MODULE COMPUTER DATA LINES SYSTEM FRONT PARKING AID WARNING BUZZER FUSE 32 FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/WHT WIRE GRY/YEL WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR LEFT REAR PARKING AID SENSOR NCA WIRE ORG/BLU WIRE ORG/BRN WIRE PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE CONTROL MODULE PARKING AID BUTTON PUSH BUTTON ILLUMINATION BULB REAR PARKING AID WARNING BUZZER RED/WHT WIRE RED/YEL WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR RIGHT REAR PARKING AID SENSOR YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Parking assistant circuit, w/ parallel parking -> BRN WIRE

Wiring diagram brn (120 of 147)

Wiring diagram brn for Audi S3 8V facelift (2016-2020) (120 of 147)

Get lifetime access to Audi S3 8V facelift (2016-2020)

4 DOOR 4 DOOR, 5 DOOR 2 DOOR 5 DOOR BRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE 53 FUSE 7 FUSE PANEL C HOT AT ALL TIMES NCA WIRE ORG/BRN WIRE ORG/GRN WIRE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER BUTTON REAR WINDOW DEFOGGER INDICATOR LAMP REAR WINDOW DEFOGGER RELAY VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE WINDSHIELD ANTENNA SUPPRESSION FILTER YEL/RED WIRE

Go to component -> Rear defogger circuit -> BRN WIRE
