Audi RS7 II (2019-2024) Most data bus circuit

BOTTOM COUPLING POINT ON LEFT A-PILLAR CENTER COUPLING POINT ON INSTRUMENT PANEL GRN WIRE GRN/VIO WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE TV TUNER (IF EQUIPPED) W/O TV TUNER WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
