Front heated seats circuit, w/o ventilation w/ sport seats for Audi RS7 II (2019-2024)

BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT DRIVER BACKREST HEATING ELEMENT DRIVER HEATED SEAT EXTENSION DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT DRIVER SEAT HEATING ELEMENT FUSE 10 FUSE PANEL D (LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT TEMPERATURE SENSOR ORG/BRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE

BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN RIGHT FRONT FRONT INFORMATION DISPLAY CONTROL HEAD FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER HEATED SEAT EXTENSION FRONT PASSENGER SEAT BOLSTER HEATER FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT HEATING ELEMENT GRN WIRE LEFT SEAT HEATING BUTTON ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RIGHT FRONT SEAT TEMPERATURE SENSOR RIGHT SEAT HEATING BUTTON SEAT OCCUPANT DETECTION SYSTEM CONTROL MODULE WHT WIRE WHT/VIO WIRE
