Radio circuit, w/ bang & olufsen sound for Audi RS7 I facelift (2014-2018)

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE DIGITAL SOUND SYSTEM CONTROL MODULE FUSE 1 GRN WIRE GRN/YEL WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT REAR BASS SPEAKER MOST DATA BUS CIRCUIT NOISE REDUCTION MICROPHONE 1 NOISE REDUCTION MICROPHONE 2 NOISE REDUCTION MICROPHONE 3 NOISE REDUCTION MICROPHONE 4 RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT REAR BASS SPEAKER SUBWOOFER VIO/BLU WIRE VIO/GRY WIRE WHT WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/YEL WIRE CENTER SPEAKER CENTER SPEAKER 2 COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE LEFT EFFECTS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER, MOTOR LEFT REAR TREBLE SPEAKER RED/YEL WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR RIGHT REAR TREBLE SPEAKER VIO WIRE VIO/BLU WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DVD CHANGER (W/ CD CHANGER) EXTERNAL AUDIO SOURCE CONNECTION FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 1 FUSE 11 FUSE 2 FUSE CARRIER 1 FUSE CARRIER 2 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/VIO WIRE GRY WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 MOST DATA BUS CIRCUIT ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RIGHT END OF DASH) YEL WIRE

ANTENNA ANTENNA AMPLIFIER ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER 3 BLK WIRE BLU WIRE BRN WIRE DIGITAL RADIO ANTENNA GPS ANTENNA GRN WIRE GRY WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 INTERIOR MICROPHONE LEFT "C" PILLAR) LEFT FRONT MICROPHONE LTE ANTENNA 2 MICROPHONE UNIT NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/GRN WIRE RED/VIO WIRE RIGHT FRONT MICROPHONE ROOF ANTENNA SATELLITE ANTENNA TELEPHONE BASE PLATE W/ DIGITAL RADIO

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLUETOOTH ANTENNA BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY -CLOSED -STOP SWITCH DISPLAY -OPEN -STOP SWITCH DISPLAY OPENING/ CLOSING MOTOR DISPLAY PIVOT MECHANISM DISPLAY UNIT BUTTON FUSE 12 FUSE 3 FUSE 7 FUSE CARRIER 3 FUSE CARRIER 4 FUSE PANEL F GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE PERIPHERAL CAMERA CONTROL MODULE REAR VIEW CAMERA SYSTEM CONTROL MODULE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA W/O REAR VIEW CAMERA W/ REAR VIEW CAMERA W/ NOISE REDUCTION W/O NOISE REDUCTION WHT WIRE WHT/GRN WIRE YEL WIRE YEL/WHT WIRE
