Radio circuit, premium w/ navigation for Audi RS7 I facelift (2014-2018)

BLK WIRE BLK/YEL WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 11 FUSE 12 FUSE 2 FUSE 3 FUSE CARRIER 1 FUSE CARRIER 2 FUSE CARRIER 3 FUSE PANEL B FUSE PANEL F GPS ANTENNA GRN WIRE GRN/VIO WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL C INFORMATION ELECTRONICS CONTROL MODULE 1 LTE ANTENNA 2 MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RIGHT END OF DASH) ROOF ANTENNA SATELLITE ANTENNA SOUND SYSTEM W/ NOISE REDUCTION W/O NOISE REDUCTION W/ EMERGENCY CALL W/O EMERGENCY CALL WHT/GRN WIRE YEL/WHT WIRE

ANTENNA AMPLIFIER 3 BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CLOSED STOP SWITCH COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA DISPLAY OPENING/ CLOSING MOTOR DISPLAY PIVOT MECHANISM DISPLAY UNIT BUTTON DVD CHANGER FRONT INFORMATION DISPLAY CONTROL HEAD GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE OPEN STOP SWITCH ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE PERIPHERAL CAMERA CONTROL MODULE REAR VIEW CAMERA SYSTEM CONTROL MODULE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE SOUND SYSTEMS TELEPHONE BASEPLATE W/ CD CHANGER W/ DIGITAL RADIO W/ REAR VIEW CAMERA W/O DIGITAL RADIO W/O REAR VIEW CAMERA W/O REAR VIEW CAMERA W/ REAR VIEW CAMERA WHT WIRE WHT/GRN WIRE YEL WIRE YEL/WHT WIRE

ANTENNA AMPLIFIER ANTENNA AMPLIFIER 2 BLK WIRE BLU WIRE BRN WIRE EXTERNAL AUDIO SOURCE CONNECTION GRN WIRE GRY WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE NOISE REDUCTION MICROPHONE 1 NOISE REDUCTION MICROPHONE 2 NOISE REDUCTION MICROPHONE 3 NOISE REDUCTION MICROPHONE 4 ORG/ WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE USB CONNECTION BASEPLATE W/O DIGITAL RADIO W/ DIGITAL RADIO WHT WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE ENGINE CONTROLS SYSTEM FUSE 7 FUSE CARRIER 4 FUSE PANEL F GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES INTERIOR MICROPHONE LEFT EFFECTS SPEAKER LEFT FRONT BASS SPEAKER LEFT FRONT MICROPHONE LEFT FRONT MIDRANGE SPEAKER LEFT FRONT SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER MICROPHONE UNIT MOST DATA BUS CIRCUIT RED/GRN WIRE RED/GRY WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT MICROPHONE RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS SUBWOOFER VIO WIRE VIO/BRN WIRE VIO/YEL WIRE W/ BOSE SOUND SYSTEM WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE
