Audi RS7 I facelift (2014-2018) Heated seats circuit, w/o memory & ventilation

BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BOLSTER HEATER DRIVER SEAT HEATING ELEMENT FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER SEAT BOLSTER HEATER FRONT PASSENGER SEAT HEATING ELEMENT FUSE 15 FUSE CARRIER 2 FUSE PANEL B GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT SEAT HEATER LEFT FRONT SEAT TEMPERATURE SENSOR ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER RIGHT FRONT SEAT TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 10 FUSE 11 FUSE CARRIER 1 FUSE CARRIER 4 FUSE PANEL B FUSE PANEL F GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEATED DRIVER SEAT ADJUSTER HEATED FRONT PASSENGER SEAT ADJUSTER HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT REAR BACKREST HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT LEFT REAR HEATED SEAT REGULATING SWITCH LEFT REAR HEATED SEAT TEMPERATURE SENSOR LEFT REAR SEAT HEATER LEFT SEAT HEATING BUTTON NCA WIRE ORG/BLU WIRE ORG/BRN WIRE REAR A/C DISPLAY CONTROL HEAD RED WIRE RED/BRN WIRE RED/VIO WIRE RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR HEATED SEAT REGULATING SWITCH RIGHT REAR HEATED SEAT TEMPERATURE SENSOR RIGHT REAR SEAT HEATER RIGHT SEAT HEATING BUTTON SEAT HEATING CONTROL MODULE VIO WIRE W/ BASIC CLIMATRONIC YEL WIRE
