Car Wiring Diagrams for Auxiliary heater circuit for Audi RS6 C8 (2019-2024)

AUXILIARY AIR HEATER HEATING ELEMENT AUXILIARY COOLANT HEATER BUTTON AUXILIARY HEATER FUSE AUXILIARY HEATER FUSE 2 BLK WIRE BRN WIRE CENTER INSTRUMENT PANEL SWITCH MODULE COMPUTER DATA LINES SYSTEM FUSE 10 FUSE PANEL D GRN/VIO WIRE HIGH HEAT OUTPUT RELAY HOT AT ALL TIMES LOW HEAT OUTPUT RELAY RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE
