Audi RS6 C8 (2019-2024) transverse selector lever lock motor Wiring diagram
This page shows the only wiring diagram for the component.transverse selector lever lock motor, which is found in the car Audi RS6 C8 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transverse selector lever lock motor (1 of 1)
4-PIN CONNECTOR
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 4
FUSE PANEL F
GRN WIRE
GRY WIRE
HEATED STEERING WHEEL SENSOR
HORNS SYSTEM
HOT AT ALL TIMES
LEFT MULTI-FUNCTION BUTTONS
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK BUTTON
PARKING LOCK INDICATOR LAMP
PNK WIRE
RED WIRE
RED/VIO WIRE
RIGHT MULTI-FUNCTION BUTTONS
SELECTOR LEVER (BASE OF SHIFT LEVER ASSEMBLY)
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
SPIRAL SPRING
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL HEATING BUTTON
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VIO WIRE
Go to component -> A/t circuit (2 of 2) -> TRANSVERSE SELECTOR LEVER LOCK MOTOR
