Audi RS6 C8 (2019-2024) transmission fluid cooling pump Wiring diagrams
This page contains all the electrical diagrams for the component. transmission fluid cooling pump, in which he is found in the car Audi RS6 C8 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transmission fluid cooling pump (1 of 2)
AFTER-RUN COOLANT PUMP
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRAKE PEDAL POSITION SENSOR
CAMSHAFT ADJUSTMENT VALVE 1
CAMSHAFT ADJUSTMENT VALVE 2
CHARGE AIR COOLING PUMP
COOLANT RECIRCULATION PUMP
CRANKCASE VENTILATION THERMAL RESISTOR 2
CRANKCASE VENTILATION VALVE
CYLINDER 5 INTAKE CAM ACTUATOR 1
CYLINDER 6 INTAKE CAM ACTUATOR 1
ELECTRIC COMPRESSOR CONTROL MODULE
ELECTRICAL COMPRESSOR BYPASS DOOR VALVE
ENGINE COMPONENT POWER SUPPLY RELAY
ENGINE COUPLING POINT 2
ENGINE/MOTOR CONTROL MODULE
EXHAUST CAMSHAFT ADJUSTMENT VALVE 1
EXHAUST CAMSHAFT ADJUSTMENT VALVE 2
EXHAUST DOOR CONTROL UNIT
EXHAUST DOOR CONTROL UNIT 2
FROM MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY (DIAGRAM 7 OF 9)
FUEL PUMP CONTROL MODULE
FUEL TANK LEAK DETECTION MODULE
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL A
GRY/RED WIRE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
MAP CONTROLLED ENGINE COOLING THERMOSTAT
OIL LEVEL THERMAL SENSOR
OXYGEN SENSOR 1 (BEFORE CATALYTIC CONVERTER)
OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER
PISTON COOLING NOZZLE CONTROL VALVE
POSITIVE CRANKCASE VENTILATION HEATING ELEMENT
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 2
STARTER GENERATOR
TO COOLANT RECIRCULATION PUMP (DIAGRAM 8 OF 9)
TRANSMISSION FLUID COOLING PUMP
VIO/RED WIRE
WASTEGATE BYPASS REGULATOR VALVE
WHT/GRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (9 of 9) -> TRANSMISSION FLUID COOLING PUMP
Wiring diagram transmission fluid cooling pump (2 of 2)
ABS CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRAKE BOOSTER CONTROL MODULE
BRAKE LAMP SWITCH
BRAKE PEDAL POSITION SENSOR
BRN WIRE
COOLING FANS SYSTEM
ENGINE/MOTOR CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL A
GRN/BLK WIRE
GRN/BLU WIRE
GRY/RED WIRE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
STARTING/ CHARGING SYSTEM
TRANSMISSION FLUID COOLING PUMP
VIO/BLK WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 4.0l turbo hybrid (3 of 12) -> TRANSMISSION FLUID COOLING PUMP
