Audi RS5 F5 facelift (2019-2024) vio Wiring diagrams

BATTERY BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT FUSE PANEL A GENERATOR, VOLTAGE REGULATOR INSTRUMENT CLUSTER CONTROL MODULE MAIN FUSE CARRIER ORG/BRN WIRE RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT STARTER SUPPLEMENTAL RESTRAINTS SYSTEM VIO WIRE VIO/BLU WIRE VIO/WHT WIRE

BLK/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT ELECTRO- MECHANICAL PARKING BRAKE BUTTON FUSE 11 FUSE PANEL 1 FUSE PANEL F GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BRN WIRE PARKING BRAKE INDICATOR LAMP PNK WIRE RED/WHT WIRE RELAY & FUSE PANEL 2 RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT FOG LAMP BULB RIGHT FRONT HEADLAMP RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP CURRENT CODING RESISTANCE 1 RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT HID HEADLAMP BULB RIGHT LIGHT CONTROL MODULE RIGHT LOW BEAM HEADLAMP REFLECTOR MOTOR VIO WIRE VIO/GRN WIRE VIO/YEL WIRE W/O LEVEL CONTROL SYSTEM WHT WIRE YEL WIRE

BLK/BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOG LAMP BUTTON FOG LAMP INDICATOR LAMP FUSE 11 FUSE 12 FUSE 13 FUSE 3 FUSE 9 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B FUSE PANEL C GRN WIRE GRY WIRE GRY/RED WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT SIDE MARKER LAMP LEFT FRONT TURN SIGNAL LAMP LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HEADLAMP CURRENT CODING RESISTANCE 1 LEFT HEADLAMP CURRENT CODING RESISTANCE 2 LEFT HEADLAMP CURRENT CODING RESISTANCE 3 LEFT HEADLAMP CURRENT CODING RESISTANCE 4 LEFT HEADLAMP CURRENT CODING RESISTANCE 5 LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3 LEFT HEADLAMP TEMPERATURE SENSOR 4 LEFT HEADLAMP TEMPERATURE SENSOR 5 LEFT HIGH BEAM HEADLAMP LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LIGHT CONTROL MODULE LEFT LOW BEAM HEADLAMP LEFT STATIONARY CORNERING LAMP LIGHT SWITCH ORG/BRN WIRE PARKING BRAKE INDICATOR LAMP POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/WHT WIRE W/O HIGH BEAM ASSIST WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BLK/BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOG LAMP BUTTON FOG LAMP INDICATOR LAMP FUSE 11 FUSE 12 FUSE 13 FUSE 3 FUSE 9 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B FUSE PANEL C GRN WIRE GRY WIRE GRY/RED WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT TURN SIGNAL LAMP LEFT HEADLAMP AUXILIARY FUNCTIONS POWER OUTPUT MODULE LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HEADLAMP CURRENT CODING RESISTANCE 1 LEFT HEADLAMP CURRENT CODING RESISTANCE 2 LEFT HEADLAMP CURRENT CODING RESISTANCE 3 LEFT HEADLAMP CURRENT CODING RESISTANCE 4 LEFT HEADLAMP FAN LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3 LEFT HEADLAMP TEMPERATURE SENSOR 4 LEFT HEADLAMP TEMPERATURE SENSOR 5 LEFT HIGH BEAM HEADLAMP LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LIGHT CONTROL MODULE LEFT LOW BEAM HEADLAMP LEFT MATRIX HEADLAMP POWER OUTPUT MODULE LEFT STATIONARY CORNERING LAMP LIGHT SWITCH ORG/BRN WIRE PARKING BRAKE INDICATOR LAMP POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/WHT WIRE W/O HIGH BEAM ASSIST WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

4-PIN CONNECTOR BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 12 FUSE PANEL C HEATED STEERING WHEEL HEATED STEERING WHEEL SENSOR HOT AT ALL TIMES LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE RED WIRE RED/VIO WIRE SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL HEATING BUTTON STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE VIO WIRE VIO/YEL WIRE

BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER BACKREST ADJUSTMENT SWITCH DRIVER MULTI- CONTOUR SEAT CONTROL MODULE DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT BOLSTER/ BACKREST INFLATION ADJUSTMENT VALVE BLOCK DRIVER SEAT FORWARD/ BACK ADJUSTMENT SWITCH DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT SWITCH MODULE DRIVER SIDE MASSAGE FUNCTION BUTTON EARLY PRODUCTION FUSE 3 FUSE PANEL 2 FUSE PANEL B GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES LATE PRODUCTION LEFT FRONT SEAT COUPLING STATION POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY & FUSE PANEL 1 VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM EARLY PRODUCTION FRONT PASSENGER BACKREST ADJUSTMENT MOTOR FRONT PASSENGER BACKREST ADJUSTMENT SWITCH FRONT PASSENGER MASSAGE FUNCTION BUTTON FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE FRONT PASSENGER PASSENGER SEAT FORWARD/ BACK ADJUSTMENT SWITCH FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER SEAT ANGLE ADJUSTMENT SWITCH FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT BOLSTER/ BACKREST INFLATION ADJUSTMENT VALVE BLOCK FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT SWITCH FRONT PASSENGER SEAT SWITCH MODULE FUSE 3 FUSE PANEL 3 FUSE PANEL F GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES LATE PRODUCTION POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY & FUSE PANEL 2 RIGHT FRONT SEAT COUPLING STATION VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

ANGLE ADJUSTMENT BUTTON BACKREST ADJUSTMENT SWITCH BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM COUPE CONVERTIBLE CURVATURE ADJUSTMENT MOTOR FORWARD/BACK ADJUSTMENT SWITCH FRONT PASSENGER BACKREST ADJUSTMENT MOTOR FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT LUMBAR SUPPORT FRONT PASSENGER SEAT MEMORY SETTINGS CONTROL HEAD FRONT PASSENGER SEAT SWITCH MODULE FUSE 14 FUSE PANEL 2 FUSE PANEL B GRN WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HEIGHT ADJUSTMENT MOTOR HEIGHT ADJUSTMENT SWITCH HOT AT ALL TIMES MEMORY SEAT BUTTON MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY & FUSE PANEL 1 RELAY & FUSE PANEL 2 RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT SEAT COUPLING STATION VIO WIRE W/O LUMBAR SUPPORT ADJUSTMENT WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER BACKREST ADJUSTMENT SWITCH DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT SWITCH MODULE FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION RED WIRE RED/BLK WIRE RELAY & FUSE PANEL 1 RELAY & FUSE PANEL 2 VIO WIRE W/ LUMBAR SUPPORT W/O LUMBAR SUPPORT WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER BACKREST ADJUSTMENT MOTOR FRONT PASSENGER BACKREST ADJUSTMENT SWITCH FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ANGLE ADJUSTMENT BUTTON FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT SWITCH FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT SWITCH FRONT PASSENGER SEAT LUMBAR SUPPORT FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT SWITCH MODULE GRN WIRE GRY WIRE RED WIRE RED/BLK WIRE RIGHT FRONT SEAT COUPLING STATION VIO WIRE W/ LUMBAR SUPPORT W/O LUMBAR SUPPORT WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE
