Audi RS5 F5 facelift (2019-2024) nca Wiring diagrams
This page contains all the electrical diagrams for the component. nca, in which he is found in the car Audi RS5 F5 facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram nca (1 of 33)
ACTIVE STEERING CONTROL MODULE
ACTIVE STEERING MOTOR
ACTIVE STEERING MOTOR ROTOR POSITION SENSOR
ACTIVE STEERING SAFETY LOCK ACTUATOR
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE PANEL 5
FUSE PANEL B
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
NCA WIRE
PNK WIRE
PNK/WHT WIRE
RED WIRE
RELAY & FUSE PANEL 1
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component: -> Active steering control module circuit -> NCA WIRE
Wiring diagram nca (2 of 33)
4-PIN CONNECTOR IN THE STEERING WHEEL
ACCUMULATOR SOLENOID
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7
BLK/VIO WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT
FUSE 12
FUSE 4
FUSE 6
FUSE PANEL 1
FUSE PANEL 2
FUSE PANEL B
FUSE PANEL C
FUSE PANEL F
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK SENSOR
PARKING LOCK SOLENOID
PNK WIRE
RED WIRE
RED/VIO WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 2
RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
SOLENOID VALVE 1
STEERING COLUMN ELECTRONICS CONTROL MODULE
TEMPERATURE SENSOR (IN CONTROL MODULE)
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR
TRANSMISSION OUTPUT SPEED SENSOR
VIO WIRE
W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
Go to component: -> A/t circuit (1 of 2) -> NCA WIRE
Wiring diagram nca (3 of 33)
??? ???
BLK/VIO WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
D/S
ENGINE/MOTOR CONTROL MODULE
GRN WIRE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK BUTTON
PARKING LOCK INDICATOR LAMP
RED/VIO WIRE
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
SUPPLEMENTAL RESTRAINTS SYSTEM
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
Go to component: -> A/t circuit (2 of 2) -> NCA WIRE
Wiring diagram nca (4 of 33)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT
ELECTROMECHANICAL POWER STEERING INDICATOR LAMP
ELECTROMECHANICAL POWER STEERING MOTOR
FUSE 1
FUSE PANEL S
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PNK WIRE
POWER STEERING CONTROL MODULE
RED WIRE
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING TORQUE SENSOR
SUPPLEMENTAL RESTRAINTS SYSTEM
VIO WIRE
Go to component: -> Electromechanical power steering circuit -> NCA WIRE
Wiring diagram nca (5 of 33)
ANTENNA AMPLIFIER 2
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
FUSE 10
FUSE 14
FUSE 2
FUSE 5
FUSE 7
FUSE 8
FUSE PANEL 4
FUSE PANEL B
FUSE PANEL C
GRN WIRE
GRN/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT REAR SIDE PANEL COUPLING POINT ON LEFT C-PILLAR
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM
NAVIGATION SYSTEM (REAR CAMERA CIRCUIT)
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
SOUND SYSTEMS
USB
USB CHARGING SOCKET 2
USB CONNECTION 1
USB DISTRIBUTOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/RED WIRE
Go to component: -> Radio circuit, w/ amplifier (1 of 5) -> NCA WIRE
Wiring diagram nca (6 of 33)
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/BLU WIRE
CENTER SPEAKER
GRN/BRN WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT MIDRANGE SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR SIDE PANEL COUPLING POINT ON RIGHT C-PILLAR
SATELLITE TUNER ANTENNA
WHT/BRN WIRE
Go to component: -> Radio circuit, w/ amplifier (2 of 5) -> NCA WIRE
Wiring diagram nca (7 of 33)
ANTENNA AMPLIFIER 2
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE 14
FUSE 5
FUSE 8
FUSE PANEL C
GRN WIRE
GRN/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT REAR SIDE PANEL COUPLING POINT ON LEFT C-PILLAR
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT)
NAVIGATION SYSTEM (PERIPHERAL CAMERA CIRCUIT)
NAVIGATION SYSTEM (REAR CAMERA CIRCUIT)
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR SIDE PANEL COUPLING POINT ON RIGHT C-PILLAR
SATELLITE TUNER ANTENNA
SOUND SYSTEMS
USB USB CONNECTION 1
USB USB DISTRIBUTOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/RED WIRE
Go to component: -> Radio circuit, w/o amplifier (1 of 4) -> NCA WIRE
Wiring diagram nca (8 of 33)
BLK WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CENTER SPEAKER
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
FUSE 7
FUSE PANEL 4
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT FRONT BASS SPEAKER
LEFT FRONT DOOR COUPLING POINT
NCA WIRE
ORG/BRN WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RIGHT FRONT BASS SPEAKER
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT TREBLE SPEAKER
SUBWOOFER
USB
USB CHARGING SOCKET 2
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
Go to component: -> Radio circuit, w/o amplifier (2 of 4) -> NCA WIRE
Wiring diagram nca (9 of 33)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 5
FUSE PANEL 3
FUSE PANEL F
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
LEFT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
MULTIMEDIA DISPLAY UNIT 3
MULTIMEDIA DISPLAY UNIT 3 BRACKET
MULTIMEDIA DISPLAY UNIT 4
MULTIMEDIA DISPLAY UNIT 4 BRACKET
NCA WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RELAY & FUSE PANEL 2
RIGHT FRONT SEAT COUPLING STATION
RIGHT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Rear seat entertainment circuit -> NCA WIRE
Wiring diagram nca (10 of 33)
BLK WIRE
BRN WIRE
COUPE, SPORTBACK
COUPLING POINT ON LEFT C-PILLAR
FUSE 10
FUSE PANEL 3
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
HOT AT ALL TIMES
MOST DATA BUS CIRCUIT
NCA WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 2
TV ANTENNA 1 ANTENNA AMPLIFIER
TV ANTENNA 1 TV ANTENNA AMPLIFIER 1
TV ANTENNA 2 TV ANTENNA AMPLIFIER 2
TV ANTENNA 3
TV ANTENNA AMPLIFIER 3
TV TUNER
Go to component: -> Tv tuner circuit -> NCA WIRE
