Audi RS5 F5 facelift (2019-2024) driver side rollover protection igniter Wiring diagram

This page shows the only wiring diagram for the component.driver side rollover protection igniter, which is found in the car Audi RS5 F5 facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver side rollover protection igniter (1 of 1)

Wiring diagram driver side rollover protection igniter for Audi RS5 F5 facelift (2019-2024)

Get access

BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COUPE, SPORT BACK DRIVER HEAD CURTAIN AIR BAG IGNITER DRIVER SEAT BELT SWITCH DRIVER SEAT POSITION SENSOR DRIVER SIDE PEDESTRIAN PROTECTION CRASH SENSOR 2 DRIVER SIDE REAR THORAX AIR BAG IGNITER DRIVER SIDE ROLLOVER PROTECTION IGNITER DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER SIDE ROLLOVER PROTECTION IGNITER FRONT PASSENGER THORAX AIR BAG CRASH SENSOR GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE LEFT FRONT SEAT COUPLING STATION PASSENGER SIDE REAR THORAX AIR BAG IGNITER RED WIRE RIGHT FRONT DOOR COUPLING POINT VIO WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> Supplemental restraints circuit (2 of 5) -> DRIVER SIDE ROLLOVER PROTECTION IGNITER
