Audi RS5 F5 (2017-2019) power rear lid opening control module Wiring diagram
This page shows the only wiring diagram for the component.power rear lid opening control module, which is found in the car Audi RS5 F5 (2017-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power rear lid opening control module (1 of 1)
AIR BAG CONTROL MODULE (REAR OF CENTER CONSOLE)
ALARM HORN
ANTI-THEFT ALARM SYSTEM SENSOR
BLK WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
COMFORT SYSTEM CENTRAL CONTROL MODULE
DISPLAY UNIT
DISTANCE REGULATION CONTROL MODULE
DISTANCE REGULATION CONTROL MODULE 2
FRESH AIR BLOWER CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
GRY/YEL WIRE
HIGH PRESSURE SENSOR
HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL VENT MOTOR
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
PNK WIRE
PNK/WHT WIRE
POWER REAR LID OPENING CONTROL MODULE
REAR A/C DISPLAY CONTROL HEAD
REAR LID CONTROL MODULE
RIGHT FRONT DOOR COUPLING POINT
STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ DRIVER ASSISTANCE SYSTEMS W/ LEVEL CONTROL SYSTEM
W/ INTERIOR MONITORING
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 8) -> POWER REAR LID OPENING CONTROL MODULE
