Car Wiring Diagrams for Jet heater circuit for Audi RS5 8T facelift (2012-2016)

BRN WIRE COMPUTER DATA LINES SYSTEM COUPE FUSE 12 FUSE CARRIER 1 FUSE PANEL C GRY WIRE GRY/VIO WIRE HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT WASHER NOZZLE HEATER ORG/BRN WIRE ORG/GRN WIRE RED WIRE RIGHT WASHER NOZZLE HEATER VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
