Rear heated seats circuit, coupe for Audi RS5 8T facelift (2012-2016)
Rear heated seats circuit, coupe
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FUSE 3
FUSE 8
FUSE CARRIER 1
FUSE CARRIER 3
FUSE PANEL C
GRN WIRE
GRY/BLU WIRE
HEATED SEAT TEMP SENSOR
HEATED SEAT W/ ADJUSTER CONTROL MODULE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR HEATED SEAT REGULATION SWITCH
LEFT REAR SEAT HEATER
RED WIRE
RELAY/ FUSE PANEL F
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR HEATED SEAT REGULATION SWITCH
RIGHT REAR SEAT HEATER
SEAT HEATER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
