Front heated seats circuit, coupe w/o memory for Audi RS5 8T facelift (2012-2016)
Front heated seats circuit, coupe w/o memory
BACKREST HEATER
BACKREST SEAT BOLSTER HEATER
BACKREST SEAT BOLSTER HEATER BACKREST HEATER
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE (BEHIND CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT HEATER
FRONT PASSENGER'S BACKREST HEATING ELEMENT
FRONT PASSENGER'S SEAT HEATER
FUSE 5
FUSE CARRIER 2
FUSE PANEL C
GRN WIRE
GRN/BRN WIRE
HEATED DRIVER SEAT ADJUSTER
HEATED FRONT PASSENGER SEAT ADJUSTER
HOT AT ALL TIMES
LEFT FRONT SEAT TEMP SENSOR
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT SEAT TEMP SENSOR
SEAT BOLSTER HEATER
SEAT BOLSTER HEATER (IF EQUIPPED)
SEAT HEATER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
