Audi RS5 8T facelift (2012-2016) Navigation circuit, convertible standard mmi & basic mmi
Navigation circuit, convertible standard mmi & basic mmi (1 of 2)
18 PIN CONNECTOR
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 4
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTER MID- TREBLE SPEAKER
CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
FUSE 4
FUSE 5
FUSE CARRIER 3
FUSE CARRIER 5
GRN/VIO WIRE
HOT AT ALL TIMES
LEFT ANTENNA MODULE
LEFT REAR MID-BASS SPEAKER
LEFT REAR TREBLE SPEAKER
MOST DATA BUS CIRCUIT
NCA WIRE
RADIO
RADIO ANTENNA 2
RADIO, TV ANTENNA
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY/FUSE PANEL F
SATELLITE ANTENNA
SUBWOOFER (IF EQUIPPED)
TV ANTENNA 3
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
Navigation circuit, convertible standard mmi & basic mmi (2 of 2)
ANTENNA AMPLIFIER 2
BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CD/DVD CHANGER
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE CARRIER 2
FUSE PANEL D
GPS ANTENNA
GRN/VIO WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MID-BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
MOST DATA BUS CIRCUIT
NCA WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FRONT MID-BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID- BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
TIM
TV ANTENNA 1
TV ANTENNA 2
TV TUNER (IF EQUIPPED)
WHT/GRN WIRE
