Audi RS5 8T facelift (2012-2016) Driver"s memory seat circuit

ANGLE BACKREST BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER'S BACKREST ADJUSTMENT MOTOR DRIVER'S SEAT ADJUSTMENT CONTROL HEAD DRIVER'S SEAT ANGLE ADJUSTMENT MOTOR DRIVER'S SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER'S SEAT HEADREST ADJUSTMENT MOTOR/SENSOR DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR FORE/BACK GRN WIRE GRN/BLK WIRE GRY/BLK WIRE HEADREST HEIGHT HOT AT ALL TIMES MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE WHT/GRN WIRE YEL/BLK WIRE YEL/GRN WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DRIVER MEMORY SEAT CONTROL HEAD DRIVER'S BACKREST LOCK SWITCH DRIVER'S DOOR CONTROL MODULE DRIVER'S ENTRY ASSISTANCE BUTTON DRIVER'S SEAT BACKREST FORWARD STOP SWITCH DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR DRIVER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR GRN WIRE GRN/BLK WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE LUMBAR CURVATURE LUMBAR HEIGHT MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE SEATS SYSTEM WHT/GRN WIRE YEL WIRE YEL/BLK WIRE
