Ground distribution circuit for Audi RS5 8T facelift (2012-2016)
Ground distribution circuit (1 of 2)
2.0L TURBO
3.0L
4.2L
AFTER-RUN COOLANT PUMP
ANTENNA AMPLIFIER 3 SHIELD
ANTENNA AMPLIFIER 3 SHIELD, RADIO, TELEPHONE, NAVIGATION SYSTEM ANTENNA SHIELD
BLK WIRE
BRN WIRE
BRN/GRN WIRE
COOLANT FAN CONTROL MODULE, COOLANT FAN CONTROL MODULE 2 (IF EQUIPPED)
COOLANT RECIRCULATION PUMP, OIL LEVEL THERMAL SENSOR,
COUPE
DIGITAL SOUND SYSTEM CONTROL MODULE
ELECTROMECHANICAL POWER STEERING
ENGINE CONTROL MODULE (ECM), SUPPRESSOR
FM FREQUENCY FILTER (NEGATIVE WIRE)
GENERATOR, VOLTAGE REGULATOR
GRN WIRE
HIGH-MOUNTED ABS CONTROL BRAKE LIGHT MODULE
IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3
IGNITION COIL 1, IGNITION COIL 2,
IGNITION COIL 3, IGNITION COIL 4 (W/ POWER OUTPUT STAGE)
IGNITION COIL 5
MOTOR
NCA WIRE
POWER CONVERTIBLE TOP VALVE 3, REAR SPOILER CONTROL MODULE
POWER STEERING CONTROL MODULE
RADIO, DIGITAL SOUND SYSTEM CONTROL MODULE (COUPE)
TURBO 2.0L
Ground distribution circuit (2 of 2)
ACTIVE STEERING CONTROL MODULE
BLK WIRE
BRN WIRE
CIGARETTE LIGHTER, TELEPHONE TRANSCEIVER, TELEPHONE BASEPLATE, 18-PIN CONNECTOR
COLUMN ADJUSTMENT CONTROL MODULE, DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
CONTROL HEAD, CD CHANGER SWITCH MODULE, DVD CHANGER
CONVERTIBLE COUPE
COUPE
DRIVER'S BACKREST HEATING ELEMENT, DRIVER'S SEAT
DRIVER'S BACKREST HEATING ELEMENT, DRIVER'S SEAT HEATING ELEMENT
EXTERNAL AUDIO SOURCE CONNECTION SHIELD (IF EQUIPPED)
FM FREQUENCY FILTER (NEGATIVE WIRE) (CONVERTIBLE)
FRONT
FRONT INTERIOR LAMP ASSEMBLY
FRONT PASSENGER'S BACKREST HEATING ELEMENT, FRONT PASSENGER'S SEAT HEATER
HEATER
HUMIDITY SENSOR IN FRESH AIR
INFORMATION DISPLAY
INFORMATION ELECTRONICS CONTROL MODULE 1
INTAKE DUCT,
LEFT REAR DOOR CONTROL MODULE, LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
MEMORY SEAT/STEERING
PANEL VENT ILLUMINATION BULB (IF EQUIPPED),
RIGHT REAR DOOR CONTROL MODULE
START/STOP MODE BUTTON (IF EQUIPPED), EMERGENCY FLASHER BUTTON, LEFT INSTRUMENT
STRUCTURE BORNE
