Audi RS5 8T facelift (2012-2016) org/brn Wiring diagrams

This page contains all the electrical diagrams for the component. org/brn, in which he is found in the car Audi RS5 8T facelift (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

org/brn wiring diagram (71 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (71 of 93)

A/T ACCESS/START AUTHORIZATION BUTTON ACCESS/START AUTHORIZATION SWITCH ALARM HORN ALARM SYSTEM DEACTIVATION SWITCH, INTERIOR MONITORING SWITCH ANTENNA AMPLIFIER (CONVERTIBLE) ANTENNA AMPLIFIER 3 (COUPE) ANTI-THEFT ALARM SYSTEM SENSOR BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM COUPE COUPE CONVERTIBLE DRIVER'S DOOR CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE ENGINE HOOD CONTACT SWITCH FUSE 12 FUSE 6 FUSE 8 FUSE CARRIER 2 FUSE CARRIER 3 FUSE PANEL SC FUSE PANEL SD GARAGE DOOR OPENER CONTROL MODULE GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL INSTRUMENT CLUSTER LEFT ACCESS/START AUTHORIZATION ANTENNA LEFT FRONT OUTSIDE DOOR HANDLE TOUCH SENSOR LEFT TAIL LAMPS 2 LUGGAGE COMPARTMENT ACCESS/START AUTHORIZATION ANTENNA NCA WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE REAR LID LOCK/ALARM CENTRAL LOCKING SWITCH/REAR LID CENTRAL LOCKING SYSTEM MOTOR RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY/ FUSE PANEL F RIGHT ACCESS/START AUTHORIZATION ANTENNA RIGHT END OF DASH) RIGHT FRONT OUTSIDE DOOR HANDLE TOUCH SENSOR SELECTOR SENSOR LEVER SYSTEM CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE INTERIOR ACCESS/ START AUTHORIZATION ANTENNA 1 VIO/BLU WIRE VIO/WHT WIRE VIO/YEL WIRE W/ MMI W/O MMI WHT WIRE YEL WIRE

Go to component -> Anti-theft circuit -> ORG/BRN WIRE

org/brn wiring diagram (72 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (72 of 93)

2.0L TURBO BATTERY BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE ENGINE CONTROLS SYSTEM EXCEPT 2.0L TURBO FUSE PANEL A GENERATOR, VOLTAGE REGULATOR INSTRUMENT CLUSTER CONTROL MODULE ORG/BLU WIRE ORG/BRN WIRE RED WIRE RED/BRN WIRE STARTER SUPPLEMENTAL RESTRAINTS SYSTEM SUPPRESSOR TERMINAL 30 WIRE JUNCTION 2 VIO/BLU WIRE VOLTAGE STABILIZER (W/ START/STOP SYSTEM) (NEAR BATTERY) WHT WIRE

Go to component -> Charging circuit -> ORG/BRN WIRE

org/brn wiring diagram (73 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (73 of 93)

4.2L EXCEPT 4.2L 7 SPEED 8 SPEED ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ACTIVE STEERING CONTROL MODULE AIR BAG CONTROL MODULE ALL- WHEEL DRIVE CONTROL MODULE AUTOMATIC DAY/NIGHT INTERIOR MIRROR BATTERY MONITORING CONTROL MODULE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRN WIRE CVT DATA BUS ON BOARD DIAGNOSTIC INTERFACE DATA LINK CONNECTOR (DLC) DIRECTIONAL STABILIZATION ASSISTANCE CONTROL MODULE DISTANCE REGULATION CONTROL MODULE ENGINE CONTROL MODULE (ECM) ESP SENSOR UNIT 2 (UNDER DRIVER'S SEAT) EXCEPT 2.0L TURBO EXCEPT CVT FUSE 11 FUSE 5 FUSE 7 FUSE 8 FUSE CARRIER 1 FUSE CARRIER 2 FUSE PANEL D GENERATOR, VOLTAGE REGULATOR GRN/VIO WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LANE CHANGE ASSISTANCE CONTROL MODULE LANE CHANGE ASSISTANCE CONTROL MODULE 2 LEVEL CONTROL SYSTEM CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/RED WIRE ORG/VIO WIRE ORG/WHT WIRE RED/YEL WIRE RIGHT END OF DASH) SOUND SYSTEMS STRUCTURE BORNE SOUND CONTROL MODULE TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION CONTROL MODULE (TCM) DIRECT SHIFT GEARBOX (DSG) MECHATRONIC VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLU WIRE VOLTAGE STABILIZER (W/ ENGINE START/STOP SYSTEM) (NEAR BATTERY)

Go to component -> Computer data lines circuit (1 of 3) -> ORG/BRN WIRE

org/brn wiring diagram (74 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (74 of 93)

ACCESS/START AUTHORIZATION SWITCH CD CHANGER, DVD CHANGER CLIMATRONIC CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE ELECTROMECHANICAL PARKING BRAKE CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE EXTERNAL AUDIO SOURCE CONNECTION FRESH AIR BLOWER CONTROL MODULE FRONT PASSENGER'S DOOR CONTROL MODULE GRN/VIO WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE PASSENGER MEMORY SEAT CONTROL MODULE PASSENGER'S SIDE CAN SEPARATING PLUG RADIO (EXCEPT MMI) REARVIEW CAMERA SYSTEM CONTROL MODULE STEERING COLUMN ELECTRONIC SYSTEM CONTROL MODULE TIRE PRESSURE MONITORING CONTROL MODULE TOWING RECOGNITION CONTROL MODULE VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE VIO WIRE VIO/BLU WIRE VIO/YEL WIRE W/ TRAILER SOCKET

Go to component -> Computer data lines circuit (3 of 3) -> ORG/BRN WIRE

org/brn wiring diagram (75 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (75 of 93)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CLOSED POSITION SWITCH CONVERTIBLE TOP COMPARTMENT COVER LOCKING MOTOR/ LOCK/UNLOCK SWITCH CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP LEFT LOCK SWITCH CONVERTIBLE TOP LOCKING MOTOR CONVERTIBLE TOP OPEN LOCK SWITCH CONVERTIBLE TOP OPEN POSITION SWITCH GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/YEL WIRE LEFT CONVERTIBLE TOP COMPARTMENT ENCLOSURE MOTOR LOCK SWITCH LOCKING MOTOR ORG/BRN WIRE ORG/GRN WIRE POWER TOP OPERATION/WINDOW REGULATOR CENTRAL SWITCH RED WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT CONVERTIBLE TOP COMPARTMENT ENCLOSURE SWITCH UNLOCK SWITCH VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component -> Convertible top circuit (1 of 2) -> ORG/BRN WIRE

org/brn wiring diagram (76 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (76 of 93)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/PNK WIRE COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP HYDRAULIC PUMP CONVERTIBLE TOP HYDRAULIC PUMP RELAY CONVERTIBLE TOP HYDRAULIC PUMP RELAY 2 CONVERTIBLE TOP OPERATION INDICATOR LAMP FUSE 1 FUSE 3 FUSE 4 FUSE CARRIER 1 FUSE CARRIER 2 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT CONVERTIBLE TOP CLOSED POSITION SWITCH LEFT CONVERTIBLE TOP COMPARTMENT COVER/OPEN SWITCH LEFT CONVERTIBLE TOP COMPARTMENT ENCLOSURE SWITCH LEFT TENSIONING BOW SWITCH ORG/BLU WIRE ORG/BRN WIRE POWER CONVERTIBLE TOP VALVE 1 POWER CONVERTIBLE TOP VALVE 2 POWER CONVERTIBLE TOP VALVE 3 REAR INTERIOR LAMP RED WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY/FUSE PANEL F RIGHT CONVERTIBLE TOP CLOSED POSITION SWITCH RIGHT CONVERTIBLE TOP COMPARTMENT COVER SWITCH RIGHT TENSIONING BOW SWITCH UPPER TENSIONING BOW SWITCH VIO/BLK WIRE VIO/BLU WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE

Go to component -> Convertible top circuit (2 of 2) -> ORG/BRN WIRE

org/brn wiring diagram (77 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (77 of 93)

2.0L TURBO 4.2L A/T ACCELERATOR PEDAL POSITION SENSOR 1, 2 BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE CLUTCH POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL ASSEMBLY) COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DISTANCE REGULATION CONTROL MODULE ENGINE CONTROL MODULE (ECM) EXCEPT 2.0L TURBO EXCEPT 3.0L SC FUSE 5 FUSE 6 FUSE 9 FUSE CARRIER 1 FUSE PANEL C FUSE PANEL D GRN/GRY WIRE GRN/VIO WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HOT W/ MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY ENERGIZED HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED M/T ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE RED/BLK WIRE RELAY/ FUSE PANEL B RIGHT END OF DASH) THROTTLE VALVE CONTROL MODULE VIO WIRE VIO/BLU WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/VIO WIRE

Go to component -> Cruise control circuit (1 of 2) -> ORG/BRN WIRE

org/brn wiring diagram (78 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (78 of 93)

BLK WIRE BLU/BLK WIRE BLU/GRN WIRE BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE BRN/GRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH ENGINE SPEED SENSOR EXCEPT 3.0L SC GRN/VIO WIRE GRY/YEL WIRE INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE RED/BLK WIRE STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE TRANSMISSION ASSEMBLY TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN) TRANSMISSION CONTROL MODULE DIRECT SHIFT GEAR BOX (DSG) TRANSMISSION MECHATRONIC TRANSMISSION INPUT SPEED SENSOR TRANSMISSION INPUT SPEED SENSOR 1 TRANSMISSION INPUT SPEED SENSOR 2 TRANSMISSION INPUT SPEED SENSOR 3 TRANSMISSION OUTPUT SPEED SENSOR W/ DIRECT SHIFT GEAR BOX W/O DIRECT SHIFT GEAR BOX WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component -> Cruise control circuit (2 of 2) -> ORG/BRN WIRE

org/brn wiring diagram (79 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (79 of 93)

2.0L TURBO 8 SPEED A/T ACCESS/START AUTHORIZATION BUTTON BATTERY BATTERY INTERRUPT IGNITER BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM COUPE CVT EXCEPT 2.0L TURBO FUSE 12 FUSE 2 FUSE CARRIER 1 FUSE PANEL A GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RELAY/ FUSE PANEL B SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE START/STOP MODE BUTTON STARTER SUPPLEMENTAL RESTRAINTS SYSTEM TERMINAL 30 WIRE JUNCTION 2 TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION PARK SELECTOR SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ DIRECT SHIFT GEARBOX

Go to component -> Starting circuit (1 of 2) -> ORG/BRN WIRE

org/brn wiring diagram (80 of 93)

Audi RS5 8T facelift (2012-2016) org/brn wiring diagram (80 of 93)

2.0L TURBO 4.2L BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CLUTCH POSITION SENSOR COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE ENGINE CONTROL MODULE (ECM) ENGINE CONTROLS SYSTEM FUSE 10 FUSE 16 FUSE 2 FUSE 3 FUSE 9 FUSE CARRIER 1 FUSE CARRIER 2 FUSE PANEL C GRN/GRY WIRE HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER SUPPLY RELAY (TERMINAL 15) RED WIRE RED/BLK WIRE RELAY/ FUSE PANEL B STARTER RELAY (ON RELAY/FUSE PANEL B) STARTER RELAY 2 (ON RELAY/FUSE PANEL B) VIO/GRY WIRE VOLTAGE STABILIZER (W/ START/STOP SYSTEM) (NEAR BATTERY) W/ START/STOP SYSTEM W/O START/STOP SYSTEM

Go to component -> Starting circuit (2 of 2) -> ORG/BRN WIRE
