Audi RS5 8T facelift (2012-2016) center vent temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.center vent temperature sensor, which is found in the car Audi RS5 8T facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center vent temperature sensor (1 of 1)
A/C COMPRESSOR REGULATOR VALVE
A/C PRESSURE/ TEMPERATURE SENSOR
AIR FLOW DOOR MOTOR
AIR QUALITY SENSOR
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE LAMP SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CENTER VENT ADJUSTMENT MOTOR
CENTER VENT TEMPERATURE SENSOR
CLIMATRONIC CONTROL MODULE
COMPUTER DATA LINES SYSTEM
COUPE
DEFROSTER DOOR MOTOR
ENGINE COOLANT LEVEL (ECL) SENSOR
EVAPORATOR VENT TEMPERATURE SENSOR
FOOTWELL DOOR MOTOR
FOOTWELL VENT TEMPERATURE SENSOR
FUSE 10
FUSE 12
FUSE 3
FUSE 8
FUSE CARRIER 1
FUSE CARRIER 2
FUSE PANEL SC
FUSE PANEL SD
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
RECIRCULATION DOOR MOTOR
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
SOLID STATE
SUNLIGHT PHOTO SENSOR
TEMPERATURE REGULATOR DOOR MOTOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/GRY WIRE
Go to component -> Automatic a/c circuit, basic (1 of 2) -> CENTER VENT TEMPERATURE SENSOR
