Audi RS5 8T facelift (2012-2016) bench seat heating element Wiring diagram
This page shows the only wiring diagram for the component.bench seat heating element, which is found in the car Audi RS5 8T facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bench seat heating element (1 of 1)
BENCH SEAT HEATING ELEMENT
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
FUSE 3
FUSE 8
FUSE CARRIER 1
FUSE CARRIER 3
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR SEAT HEATING
LEFT REAR SEAT HEATING BUTTON
RED WIRE
RED/VIO WIRE
RELAY/ FUSE PANEL F
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR SEAT HEATING
RIGHT REAR SEAT HEATING BUTTON
SEAT HEATING CONTROL MODULE
TEMPERATURE SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Rear heated seats circuit, convertible -> BENCH SEAT HEATING ELEMENT
