Audi RS5 8T facelift (2012-2016) abs inlet Wiring diagram
This page shows the only wiring diagram for the component.abs inlet, which is found in the car Audi RS5 8T facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram abs inlet (1 of 1)
ABS CONTROL MODULE
ABS CONTROL MODULE FUSE 1
ABS HYDRAULIC UNIT
ABS INLET
ABS OUTLET
AUTO HOLD BUTTON
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVING DYNAMICS
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
FUSE 2
FUSE 6
FUSE CARRIER 2
FUSE PANEL A
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
LEFT FRONT
LEFT FRONT ABS WHEEL SPEED SENSOR
LEFT REAR
LEFT REAR ABS WHEEL SPEED SENSOR
ORG/BLU WIRE
ORG/BRN WIRE
ORG/WHT WIRE
PRESSURE SWITCH
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/VIO WIRE
REGULATION HIGH
REGULATION SWITCH
RIGHT FRONT
RIGHT REAR
VALVE
VALVE 1
VALVE 2
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 3) -> ABS INLET
