Parking assistant circuit for Audi RS3 8Y (2021-2024)

BLK/RED WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT FRONT BUMPER COUPLING POINT ON LEFT REAR BUMPER FUSE 58 FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/YEL WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR LEFT REAR PARKING AID SENSOR ORG/BRN WIRE PARKING AID CONTROL MODULE REAR PARKING AID SPEAKER REAR PARKING TREBLE SPEAKER RED/WHT WIRE RED/YEL WIRE RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR RIGHT REAR PARKING AID SENSOR WHT WIRE YEL/BLU WIRE YEL/GRY WIRE

BRN WIRE BRN/WHT WIRE GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/YEL WIRE LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP RED/WHT WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR RIGHT SIDE OF FRONT GRILLE) YEL/BLU WIRE YEL/GRY WIRE
