Audi RS3 8Y (2021-2024) driver side rear power window regulator motor control module Wiring diagram
This page shows the only wiring diagram for the component.driver side rear power window regulator motor control module, which is found in the car Audi RS3 8Y (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side rear power window regulator motor control module (1 of 1)
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COURTESY LAMPS CIRCUIT
DRIVER SIDE REAR DOOR CONTROL HEAD
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR POWER WINDOW BUTTON
DRIVER SIDE REAR POWER WINDOW REGULATOR MOTOR CONTROL MODULE
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 44
FUSE 9
FUSE PANEL C
GRN WIRE
GRN/WHT WIRE
GRY/WHT WIRE
HEADLAMP SWITCH ILLUMINATION LAMP
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT REAR DOOR COUPLING POINT
LIGHT SWITCH
ORG/BRN WIRE
OVERHEAD CONSOLE
PARKING BRAKE BUTTON
PASSENGER SIDE REAR POWER WINDOW BUTTON
PASSENGER SIDE REAR WINDOW REGULATOR MOTOR CONTROL MODULE
POSITION LAMP INDICATOR LAMP
PUSH BUTTON ILLUMINATION LAMP
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
REAR TEMPERATURE SELECTION POTENTIOMETER
RED/VIO WIRE
RIGHT REAR DOOR COUPLING POINT
ROOF ELECTRONICS CONTROL MODULE
START/STOP MODE IND LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRY WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> DRIVER SIDE REAR POWER WINDOW REGULATOR MOTOR CONTROL MODULE
