Parking assistant circuit, w/ parallel parking & driver assistance for Audi RS Q8 I (2019-2024)

BLK WIRE BLK/YEL WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT REAR BUMPER DRIVER ASSISTANCE SYSTEMS CONTROL MODULE FRONT PARKING AID WARNING BUZZER FUSE 1 FUSE 9 FUSE PANEL B FUSE PANEL J GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR LEFT REAR PARKING AID SENSOR NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE RED WIRE RED/GRN WIRE RED/YEL WIRE RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR RIGHT REAR PARKING AID SENSOR VIO WIRE VIO/BLU WIRE VIO/WHT WIRE WHT/GRN WIRE WHT/GRY WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLU/VIO WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH MODULE 1 CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT FRONT BUMPER FUSE 11 FUSE PANEL F GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR ORG/BRN WIRE PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLU WIRE WHT/GRY WIRE YEL/BLU WIRE YEL/GRN WIRE
